How to Build a Shed

A shed solves a lot of storage needs for outdoor tools and equipment. It is also a great place for work projects that won't clutter up the garage. This wikiHow will teach you how to build one.

Steps

  1. Level the ground (if necessary) and install deck piers along a grid to support the shed.The piers will allow you to string support beams beneath the floor of the shed. In the example design, the piers are spaced 6 feet (1.8 m) apart in one direction and 4 feet (1.2 m) apart in the other for a total grid area of 12 x 8 feet. This is convenient because once you lay supports along this grid, it will take exactly three standard 4- by 8-foot plywood sheets to cover it.
    • Note that in some countries, you must obtain apermitbefore doing any in-ground foundation work. If you would rather avoid this, you can build the shed on the ground by replacing the beams (see below) with 4x6-inch (102x152-mm) skids of pressure-treated lumber that is approved for ground contact, or by using precast concrete fence posts.
  2. String support beams lengthwise across the deck piers.This will support your floor joists, which run in the opposite direction. The easiest way to attach the beams to the piers is with metal straps, which have built-in nail holes. In the example design, the beams are 12-foot-long 4x6”s.
  3. Attach joists to the support beams and separate them with blocking.
    • First, you will need to attach arim joistalong the outer edge of each outermost support beam; each of these will need to be the same length as the beam underneath.
    • Then, you will need to install a series offloor joistsacross the entire length of the support beams; these will need to be the same length as the distancebetweenthe two rim joints so that they’ll fit between them. In the example design, the floor joists are all separated by 14.5-inch gaps except for the outermost two, which are133⁄4inches (34.9 cm) from their immediate neighbors; this is to allow a standard piece of plywood to line up with the outermost edge of the outermost joist but only coverhalfof an interior joist, allowing its neighbor to cover the other half so that both can be supported properly.
    • To keep the floor joists from moving, install a piece ofblockingbetween each pair of floor joists along the center support beam.
  4. Nail plywood sheeting to the joists to form the floor.If necessary, use H-clips in addition to nailing the sheets into place; these fit between two pieces of plywood and lock them together for additional structural strength. In the example design, two standard sheets of 4- by 8-foot plywood are used whole and a third is sawn in half and used to fill in the 4-foot difference on either end. Because of the spacing of the piers, support beams, and joists, no additional cuts or adjustments are necessary. Note that the pieces of plywood are intentionally misaligned so that the floor doesn’t have a single seam running across the whole thing, which would be a significant structural weakness.
    • Flooring may also be screwed down with 3-inch deck screws.
  5. Build the framework for all four walls.To account for the fact that the front and back walls are different from each other (due to the doorframe in the front) and the side walls must both be sloped (to prevent rain from collecting on the roof), each of these will have to be tackled somewhat differently. It’s easiest to construct the back first, the front second, and the two sides last, as shown in the numbered image below. See How to Frame a Wall for more information before you read the instructions below.
    • Build the framework for the back wall. Make the top and bottom beams (a.k.a. the plates) the same length as the length of the floor which they sit. To keep your measurements simply, make the spacing between the vertical studs identical to the spacing between your floor joists. Note that the back wall should be lower than the front wall so that the roof slopes and directs rain away from the door.
    • Build the framework for the front wall. The front wall should be the same as the back wall except taller and with a door frame so that you can hang a door in the shed when you’re done.
    • Build the framework for the side walls. The bottom plate of each side wall should be the same length as the distancebetweenthe bottom plates of the front and back wall (so that the side walls will fit between them). The standard spacing between vertical wall studs in the US is 16 inches (from center to center, not from edge to edge); since this stud spacing doesn’t perfectly divide into the total length of the side walls in the example design, the two outermost studs make up for this discrepancy by being slightly closer to their neighbors. Most importantly, the top plate is angled so that the roof will be sloped, which makes the height of each vertical stud slightly different. If you’re not sure how to calculate the necessary height of each vertical stud in advance, make the two outermost vertical studs first, lay them the correct distance apart, cut a top plate that spans this distance, and then cut each remaining vertical stud individually based on the distance between the top and bottom plates at that exact location.
    • Assemble the four wall structures. Wall structures are usually nailed to the underlying support from the bottom up. However, if this is not possible with the design you’ve chosen, simply nail them downwards through the plywood and joists or toenail them into place by driving the nails downwards and at an angle. Note that you will probably need other people to help you hold the wall structures up until they can be attached to one another.
  6. Build rafters across the roof and separate them with blocking.These should overhang the walls of your shed for increased weather protection. Again, your measurements will be greatly simplified if you space the rafters the same way that you spaced your floor joists. When you’re done, attach pieces of blocking between each pair of rafters along the top plates.
  7. Nail plywood sheeting to the rafters to form the roof.If you have added overhang, the plywood layout you used to cover the floor will have to be amended.
  8. Cover the walls.You can use siding, textured plywood, or anything else that gives the shed a more finished look.
  9. Add tar paper to the roof.Start from the lower end of the roof slope and work your way upwards, making sure that each new level of paper overlaps the one below it to keep rain from seeping into the cracks. You can also use shingles or other roofing material if desired.

Community Q&A

Search
  • Question
    How can I build a homemade shed?

    General Contractor
    Mark Spelman is a General Contractor in Texas. He has been a construction professional since 1987.
    General Contractor
    Expert Answer
    For the beginner, there are a lot of pre-cut kits that you can buy at local hardware store. You can also find a lot of building plans online that will be easy to follow.
    Thanks!
  • Question
    Can I make a shed out of balsa wood without breaking it?

    General Contractor
    Mark Spelman is a General Contractor in Texas. He has been a construction professional since 1987.
    General Contractor
    Expert Answer
    This would be for modeling only. Balsa wood is used for designing small mock-ups of design.
    Thanks!
  • Question
    What is the approximate cost of building a shed?
    wikiHow Contributor
    Community Answer
    It depends on the size and type of shed. I'm building a 10x10 shed with a gambrel roof. My guess at this point 00 to 00.
    Thanks!
  • Question
    How do I secure the roof to the rafters?
    wikiHow Contributor
    Community Answer
    If you are just going with a sloped roof, as in the video, you nail the sheets of plywood to the roof rafters.
    Thanks!
  • Question
    Do I need to anchor floor supports in concrete?
    wikiHow Contributor
    Community Answer
    It is highly recommended that you do so as any lateral stress on the building (high winds, uneven weight distribution, etc.) can cause settling in the supports, and the building will eventually become uneven, which can cause a number of issues such as cracked siding, improper stress on framing studs, and in extreme cases, total collapse.
    Thanks!
  • Question
    How many nails are needed to build a small-size shed?
    wikiHow Contributor
    Community Answer
    20 pounds of nails should be enough.
    Thanks!
  • Question
    Do I need felt paper on wall sheathing before cedar siding installation?
    wikiHow Contributor
    Community Answer
    No, you do not.
    Thanks!
Unanswered Questions
  • How can I build a shed out of wooden pallets?
  • What is height difference of frog wall and back wall?
Ask a Question
200 characters left
Include your email address to get a message when this question is answered.

Video


How to build a shed - Part 1.

Short Video: How to Build a Shed

Watch
Did this video help you?
Watch Again

To construct the floor of your shed, install deck piers and fasten support beams lengthwise. Nail horizontal floor joists and plywood sheets on top. Build the walls and rafters out of wood beams, and make sure to build the back wall slightly shorter to create a slant. Then, cover with plywood.

  • Let your shed breathe
  • You may want to stain or paint your shed to make it last longer.
  • Don’t scrimp on windows
  • If you plan to finish the inside, you should add an additional stud in each corner for a nailing surface.
  • A ramp instead of stairs will allow you to move wheeled equipment in and out of the shed easily.
  • You may want to install a corrugated fiberglass roof for natural light.
  • Click on images to get the best view. Some information is lost in the thumbnail view.
  • Pick a good spot. There are two different types of shed builders; those who pick shed spots based on aesthetics and those who choose the first available spot. Unfortunately neither of these is effective ways to choose where to build your shed.

Things You’ll Need

  • Deck piers (see linked article in Step 1)
  • 16d nails for the framing
  • 8d nails for the sheeting
  • 4- by 6-inch (10- by 15-cm) beams for support
  • 2- by 6-inch (5- by 15-cm) beams for joists, rafters, and blocking
  • 3/4-inch (2-cm) plywood for flooring
  • 2- by 4-inch (5- by 10-cm) beams for studs and plates
  • 4- by 4-inch (10- by 10-cm) beams for frame headers
  • 1/2-inch (127-mm) plywood for roofing
  • textured plywood (or siding) for the walls
  • tar paper for the roof

Warnings

  • Don't nail your finger!
  • If you haven't done so before, have your property line surveyed and marked
  • Check the zoning in your location to see if a shed is allowed.
  • Before you begin construction check local laws at your town's building department to see if a permit is needed.
